Jairaj Metals is an authorized Aluminium Manufacturer, Supplier and Exporter in India. From Round Bars to Aluminium Pipe Fittings, we have a tight control on thickness, width and diameter, which means clients will get the exact specification. Our Aluminium range includes 1100, 2011, 2024, 3003, 5052, 5083, 6061, 6063 and 7075, for a range of compositions to meet various needs from simple fabrication to aerospace grade strength.
Specification of Aluminium
| Aluminium Specifications |
| Grades |
C61300, C61400, C61900, C62300, C62400, C63000, C63020, C63200, C64200, and C64210.
|
| Specifications |
AMS 4640, AMS 4880, AMS 4881, AMS 4590, ASTM B150, ASME SB150
|
| Surface |
Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline
|
| Technique |
Aluminum Bronze Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod
|
| Aluminium Products |
Aluminium Flanges, Aluminium Round Bar, Aluminium Pipe Fitting, Aluminium Ferrule Fittings, Aluminium Fasteners, Aluminium Sheet/Plate/Coil, Aluminium Forged Fitting, Aluminium Valves, Aluminium Capillary Tubes and many more. |
Chemical Composition of Aluminium
Chemical Composition of Aluminium
| Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Al |
| 1070 |
0.20 |
0.25 |
0.04 |
0.03 |
0.03 |
— |
0.04 |
0.03 |
99.70 |
| 1060 |
0.25 |
0.35 |
0.05 |
0.03 |
0.03 |
— |
0.05 |
0.03 |
99.60 |
| 1050 |
0.25 |
0.40 |
0.05 |
0.05 |
0.05 |
— |
0.05 |
0.03 |
99.50 |
| 1350 |
0.10 |
0.40 |
0.05 |
0.01 |
— |
0.01 |
0.05 |
— |
99.50 |
| 1145 |
0.55 Si + Fe |
0.05 |
0.05 |
0.05 |
— |
0.05 |
0.03 |
0.03 |
|
| 1100 |
0.95 Si + Fe |
0.05-0.20 |
0.05 |
— |
— |
0.10 |
— |
0.05 |
|
| 2024 |
0.50 |
0.50 |
3.8-4.9 |
0.30-0.9 |
1.2-1.8 |
0.10 |
0.25 |
0.15 |
Rem. |
| 3003 |
0.6 |
0.7 |
0.05-0.20 |
1.0-1.5 |
— |
— |
0.10 |
— |
Rem. |
| 3004 |
0.30 |
0.7 |
0.25 |
1.0-1.5 |
0.8-1.3 |
— |
0.25 |
— |
Rem. |
| 3005 |
0.6 |
0.7 |
0.30 |
1.0-1.5 |
0.20-0.6 |
0.10 |
0.25 |
0.10 |
Rem. |
| 3104 |
0.6 |
0.8 |
0.05-0.25 |
0.8-1.4 |
0.8-1.3 |
— |
0.25 |
0.10 |
Rem. |
| 4004 |
9.0-10.5 |
0.8 |
0.25 |
0.10 |
1.0-2.0 |
— |
0.20 |
— |
Rem. |
| 4104 |
9.0-10.5 |
0.8 |
0.25 |
0.10 |
1.0-2.0 |
— |
0.20 |
— |
Rem. |
| 4043 |
4.5-6.0 |
0.8 |
0.30 |
0.05 |
0.05 |
— |
0.10 |
0.20 |
Rem. |
| 4045 |
9.0-11.0 |
0.8 |
0.30 |
0.05 |
0.05 |
— |
0.10 |
0.20 |
Rem. |
| 5005 |
0.30 |
0.7 |
0.20 |
0.20 |
0.50-1.1 |
0.10 |
0.25 |
— |
Rem. |
| 5050 |
0.40 |
0.7 |
0.20 |
0.10 |
1.1-1.8 |
0.10 |
0.25 |
— |
Rem. |
| 5052 |
0.25 |
0.40 |
0.10 |
0.10 |
2.2-2.8 |
0.15-0.35 |
0.10 |
— |
Rem. |
| 5252 |
0.08 |
0.10 |
0.10 |
0.10 |
2.2-2.8 |
— |
0.05 |
— |
Rem. |
| 5056 |
0.30 |
0.40 |
0.10 |
0.05-0.20 |
4.5-5.6 |
0.05-0.20 |
0.10 |
— |
Rem. |
| 5657 |
0.08 |
0.10 |
0.10 |
0.03 |
0.6-1.0 |
— |
0.05 |
— |
Rem. |
| 5182 |
0.20 |
0.35 |
0.15 |
0.20-0.50 |
4.0-5.0 |
0.10 |
0.25 |
0.10 |
Rem. |
| 6061 |
0.40-0.8 |
0.7 |
0.15-0.40 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
Rem. |
| 7075 |
0.40 |
0.50 |
1.2-2.0 |
0.30 |
2.1-2.9 |
0.18-0.28 |
5.1-6.1 |
0.20 |
Rem. |
Mechanical Properties of Aluminium
Mechanical Properties of Aluminium
| Alloy |
Temper |
Proof Stress
0.20% (MPa) |
Tensile Strength
(MPa) |
Shear Strength
(MPa) |
Hardness Brinell
HB |
Hardness Vickers
HV |
| AA2011 |
0 |
35 |
80 |
50 |
21 |
20 |
| AA2011 |
T4 |
270 |
350 |
210 |
90 |
95 |
| AA2011 |
T6 |
300 |
395 |
235 |
110 |
115 |
| AA2011 |
T8 |
315 |
420 |
250 |
115 |
120 |
| AA6082 |
0 |
60 |
130 |
85 |
35 |
35 |
| AA6082 |
T5 |
275 |
325 |
195 |
90 |
95 |
| AA6082 |
T6 |
310 |
340 |
210 |
95 |
100 |
| AA7075 |
0 |
105 |
225 |
150 |
60 |
65 |
| AA7075 |
T6 |
505 |
570 |
350 |
150 |
160 |
| AA7075 |
T7 |
435 |
505 |
350 |
140 |
150 |
| AA7075-R |
- |
645 |
- |
- |
- |
- |
| AA7075-S |
- |
167 |
- |
- |
- |
- |
